ZS-450型振動篩分機

ZS-450NOISELESS HIGH-EFFICIENCY VIBRATOR AND SCREENING MACHINE

一、適用行業：本產品適用于食品、制藥、化工、陶瓷、粉末冶金、塑料、橡膠、研磨、污水處理。。。行業。

APPLICATIONS：THIS MACHINE CAN BE USED IN MAKING FOOD、MEDICINE CHEMICALS、CERAMICSRILES、POWDER METAL、PLASTICS AND RUBBER AS WELL AS IN ABRASIVES AND POLLUTION TREATMENT。

二、特性 SPECIAL FEATURES

參數 REFERENCE FIGURES

馬力 MOTOR （HP）	電壓 POWER （VAC）	頻率 FENQUENCY HZ	轉速 speed （rpm）	篩面有效直徑 effective diameter (mm)	允許 **給料粒度 maximum particle size (mm)	處理能力 capacity city tons/hr	凈重 net wl (kg)
1/2	220/380/415	50	1440	400	10-15	0.1-2.5	44

三、零部件對照 components of parts and assembles

項目 item	品名規格 part name and specification	數量 number	備注 note	項目 item	品名規格 part name and specification	數量 number	備注 note
1	電機machine	1		7	機座 MACHINE BASE	1	SS41
2	振動塊 VIBRATOR PLATE	2	SS41	8	出料斗 OUTGET PANNEL	1	SUS304
3	底座 BASE PLATE	1	SS41	9	蓋型螺母CAPPED BOLT	4	SUS304
4	避振膠墊 PLASTIC ANTI-VIBRATION ARM	3	NR	10	篩盤 SCREEN PAN	1	SUS304
5	壓縮彈簧 COMPRESSED SPRING	12	MN65	11	篩網 SCREEN	1	SUS304
6	壓縮彈簧固定座 COMPRESSED SPRING HOLDER BASE	24	POM	12	拉鉤 PULL hook	3	SUS304

四、注意事項 PLEASE NOTE THE FOLLOWING

1、檢查您所訂購的形式和規格是否相符，所配電源與銘牌標示是否一致（電壓誤差±10%）；

PLEASE CHECK THE MODEL AND SPECIFICATIONS IN YOUR ORDER TO ENSURE THAT THEY ARE CORRECT（VOLTAGE DIFFERENCE MUSTNOT EXCEED5%）

2、檢查緊固部分是否松動？電源開關（不可用閘刀開關）及接地線安裝是否保證接觸良好？嚴禁電機缺相運轉；

CHECK IF THE TIGHTENING PARTS AND CABLES ARE PROPERLY INSTALLED. NB .POWER SWTICH SHOULD BE PROPERLY CONNECTED INCLUDING THE EARTH WIRE .INCOMPLETE INSTALLATION IS STRICTLY PROHIBITED WHICH WILLCAUSE DAMAGE.

3、電機引出線在機座內側必須預留80mm的的伸縮量，保證設備振動時引線不被拉斷；

ENSURE THAT THE CABLE MUST HAVE AT LEAST 60MM EXTRA LENGTH AT THEMACHINE BASE TO AVOID SNAPPING DUE TO VIBRATION WHEN THE MACHIEIS IN OPERATION.

4、本機器放置在與四周*小保持500mm距離的地方，且機器安裝平穩、可靠；

THE MACHINE SHOULD BE PLACED ABOUT 500MM,AWAY FROM OTHERS OBJECTS TO AVOID KNOCKING

5、本產品出廠時已設定上下平衡塊順時針呈45度夾角（固定上部，旋轉下部平衡塊至45度），若使用效果不佳，可參考工作原理自行調節，調整后鎖緊平衡塊緊固螺絲；

THE STANDARD ROTATIONAL ANGLE HAS BEEN SET AT 45°（CLOCK -WISE）.IF RESULT IS IDEAL,IT CAN BE READJUSTED TO ACHIEVE REQUIREMENT ENSURE THAT THE BALANCE ARM ARE WELL THIGTEN AFTER THE ADJUSTMENT.

6、不使用時要切斷電源、清洗時嚴禁用水清洗電機、以防漏電；

SWITCH OFF POWER WHEN NOT IN OPERATION .DO NOT CLEAN THE MOTOR WITH WATER TO AVOID DAMAGE ANG ELECTRICAL SHOCK.

7、要保證絲網清潔，可根據物質不同、采用相應清洗劑、同時篩面嚴禁用尖銳物體碰撞；

ALLWAYS KEEP SCREEN CLEAN TO ACHIEVE BEST RESULT.THE MACHINE DOES NOT NEED TO STOP DURING SCREEN CLEANING PROCESS.USE DIFFERENT CLEANING METHOD BSASED ON THE TYPE OF MATERIAL FILTERED .AVOID USING USING HARD OR SHARP OBJECT TO CLEAN THE NET.

8、本產品正常使用條件下質保期為壹年，在質保期內，使用中若發生異常，請立即停機檢查并及時與本公司聯系，切勿自行拆卸。

SWITCH OFF THE MACHINE AND CHECK ONCE ANUNUSUAL NOISE IS HEARD.
